About Us - Our Machine Services



CNC Equipment

Machine

Travel

Spindle Speed

Notes

2013 Mazak Variaxis i-700

24" x 43" x 24"

12,000 RPM

5 Axis capability

2013 Mazak Variaxis i-600

20" x 36" x 20"

12,000 RPM

5 Axis capability

2013 Mazak Integrex i-200

24" x 10" x 42"

Main spindle - 5,000 RPM; Second spindle - 5,000 RPM;
12,000 RPM milling spindle

7 Axis capability

2012 Mazak Integrex i-200

24" x 10" x 42"

Main spindle - 5,000 RPM; Second spindle - 5,000 RPM;
12,000 RPM milling spindle

7 Axis capability

2013 Mazak Integrex i-100S

18" x 8" x 36"

Main spindle - 6,000 RPM; Second spindle - 6,000 RPM;
12,000 RPM milling spindle

7 Axis capability

2013 Mazak Integrex i-100S

18" x 8" x 36"

Main spindle - 6,000 RPM; Second spindle - 6,000 RPM;
12,000 RPM milling spindle

7 Axis capability

2013 Mazak VCN Compact

20" x 17" x 20"

12,000 RPM

5 Axis capability

2012 Mazak QT-250

9" x 22"

Main spindle - 4,000 RPM; Second spindle - 6,000 RPM

Live tooling; 3" LNS bar feed

2010 Haas VF-6SS

64" x 32" x 30"

12,000 RPM

4 Axis capability

2007 Haas VF-4SS

50" x 20" x 25"

12,000 RPM

4 Axis capability

2009 Haas VF-2

30" x 16" x 20"

15,000 RPM

5 Axis capability

2010 Haas VF-2SS

30" x 16" x 20"

12,000 RPM

4 Axis capability

2008 Haas SL-30

17" x 34" cutting capacity

3,400 RPM

30" Swing

2006 Haas TL-2 Lathe

16" x 48" cutting capacity

2,000 RPM

16" Swing

2012 ProtoTRAK SLX CNC

24" x 60"





With turret



Manual Equipment

  • Bridgeport Vertical Milling Machine - Table Size 9" x 48"
  • Manual Engine Lathe - Cutting Capacity 14" x 40"
  • Flex-Arm Tapping System
  • 16 Gauge Shear
  • 50 Ton Hydraulic Press - Manual Arbor Press
  • Jet VBS-1610 15 1/2 " Vertical Bandsaw
  • Jet 13" Horizontal Bandsaw
  • Jet 10" Vertical Bandsaw
  • Jet 10" Vertical Bandsaw
  • Kondia V-3 Mill - 10” x 50" table
  • DuAll Vertical Bandsaw - 13" x 30"
  • Various drill presses, sanders, bead blaster, grinders and hand tools



Inspection Equipment

  • LK G-80 Coordinate Measuring Machine - 40" x 36" x 24" travel
  • SCHERR-TUMICO Optical Comparator
  • Numerex Coordinate Measuring Machine
  • Various Bore Gages



Other Equipment

  • Kaltenbach - SL450 automatic cold cut saw - 6" round max; 2" x 14" rectangle
  • Vy-Tech - CNC laser Marker - 24" x 48" table w/ rotary marking option



Software

  • Mastercam CAD/CAM
  • SolidWorks

Other

Black Diamond holds four patents and is highly innovative in product design and development. Our design and engineering team works interactively with our customers to ensure the most effective and efficient product design. We follow strict customer quality control procedures. Our management team has over 90 years of collective machining and manufacturing experience.

Facilites

Black Diamond operates out of a climate controlled facility with 17,000 square feet of production and manufac-turing space and 2,000 square feet of administrative and engineering offices. We also have a 7,500 square foot facility that is used for research & development and assembly. We are centrally located in Cannon Falls, Minne-sota on a major four-lane highway 20 minutes southeast of the Minneapolis-St. Paul metropolitan area.
